Air Boom || Overall 750mm H
AB750 (1450)

Want to purchase this product?

Get in touch using one of the methods below


Phone Romold01506409973


Typically deployed from response vessels where a foam filled boom would be too bulky, the reduced volume of an air filled containment boom is also an asset when they have to be transported to a new location and are ideal for open water where the high buoyancy to weight ratio assists the performance in the waves. They have excellent UV resistance and chemical resistance to acids, alkalis, solvents and hydrocarbons. We can manufacture different sizes and material types (PU and Neoprene) please contact us to discuss your application.


Freeboard: 300mm
Draft: 414mm
Overall: 750mm
GSM PVC 1450
Section length: 25m
Buoyancy to weight: 30:1
Weight: 3.5kg per metre
Packaging volume: 0.65m³ per 25m
Ballast: 12mm hot dip galvanised chain
Fabric: Orange or yellow 850gsm woven polyester scrim coated with PVC
Breaking Strength: ASTM D 5035 (lengthwise & width wise 300kgf/5cm)
Operational temperature: 0°C to +80°C


Freeboard = vertical height of the product above the water

Draft = depth of the product below the water

Download a datasheet for AB750 (1450)
